keyboard can control the system even when there is no USB driver loaded onto the
system.
Î
Enabled D EFAULT
Legacy USB support enabled
Î
Disabled Legacy USB support disabled
Î
Auto Legacy USB support disabled if no USB devices are
connected
4.3.3 H/W Monitor
The H/W Monitor menu (BIOS Menu 6) contains the fan configuration submenus and
displays operating temperature, fan speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
H/W Monitor
CPU Temperature
:+61 C
CPU FAN Speed :3006 RPM
VCC3V :+3.392 V
V_CORE :+1.200 V
V_1.05 :+1.064 V
V_MEM :+1.616 V
VSB3 :+3.392 V
VBAT :+3.008 V
5VSB :+4.920 V
CPU Smart Fan control
[Enabled]
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 6: H/W Monitor
Î H/W Monitor
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ CPU Temperature
ƒ CPU Fan Speed
ƒ Voltages:
