IOPS-Q67/H61 Pluggable Module PC
Page 2
1.1 Overview
Figure 1-1: IOPS-Q67/H61 Series Pluggable Module PC
The IOPS-Q67/H61 series is a pluggable module PC with 2nd-generation Intel® Core™ i5
or Intel® Celeron® dual-core processor and Intel® Q67 or H61 Express Chipset. The
IOPS-Q67/H61 is preinstalled 4 GB of DDR3 SO-DIMM and can accommodate up to 8 GB
of DDR3 memory. Storage in the system is handled by the preinstalled 32 GB mSATA
module and the SDHC card slot on the front panel.
The IOPS-Q67/H61 includes a DisplayPort output interface supporting up to 2560 x 1600
resolutions. Other slots and connectors include half-size PCIe Mini card slot, RS-232,
Gigabit Ethernet, USB 2.0 ports and audio out.
The IOPS-Q67-i5 model with Intel® Core™ i5 processor also supports Intel® AMT 7.0
that make maintenance a lot easier for system integrators.
1.2 Features
The IOPS-Q67/H61 has the following features
ƒ Intel® Open Pluggable Specification (OPS) compliant
ƒ LGA1155 Intel® Core™ i5, or Celeron® G530 CPU supported
ƒ Intel® HD Graphics with full HD video decoding capability
ƒ One 32 GB mSATA module preinstalled
ƒ One SDHC card supported
ƒ One GbE LAN for high speed network applications
ƒ One DisplayPort connector
ƒ Two USB 2.0 ports
