IOPS-Q67/H61 Pluggable Module PC
Page 3
One RS-232 RJ-45 serial port
One audio line-out jack
RoHS compliant design
1.3 Model Variations
There are two models in the IOPS-Q67/H61 series. Both models are preinstalled with
4 GB of DDR3 memory and a 32 GB mSATA module. The model variations are listed in
62
Table 1-1
below.
LGA1155 CPU
Express Chipset
IOPS-Q67-i5-4GB 2.70GHz Intel® Core i5-2390T
Intel® Q67
IOPS-H61-C-4GB
2.40GHz Intel® Celeron® G530
Intel® H61
Table 1-1: Model Variations
1.4 External Overview
1.4.1 Front Panel
The IOPS-Q67/H61 front panel provides access to the following external I/O connectors:
1 x Audio line-out jack
1 x DisplayPort connector
1 x GbE RJ-45 connector
1 x RS-232 RJ-45 serial port
2 x USB 2.0 port connectors
1 x SDHC slot
1 x Storage device LED indicator
1 x USB LED indicator
1 x Status LED indicator (Blinking: booting; Solid: complete booting)
1 x Power button
1 x Reset button
An overview of the front panel is shown in
62
Figure 1-2
below.
