TANK-600 Em b e d d e d S ys te m
P a g e 66
5.4.1 Ho s t Brid g e Co n fig u ra tio n
Use the Host Bridge menu (BIOS Menu 18) to view the memory information.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
******* Memory Information *******
Memory Frequency
1067 MHz(DDR3)
Total Memory 4096 MB
DIMM1 4096 MB
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 18: Host Bridge
5.4.2 S o u th Brid g e Co n fig u ra tio n
Use the South Bridge menu (BIOS Menu 19) to configure the south bridge chipset.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Auto Power Button Status [Enable(AT)]
Azalia Controller
[HD Audio]
Mini-PCIe LAN Controller
[Enabled]
Azalia Controller
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 19:South Bridge
