TANK-600 Em b e d d e d S ys te m
P a g e 33
4.3 Exte rn a l In te rfa c e P a n e l Co n n e c to rs
The table below shows a list of the external interface panel connectors on the system
motherboard. Pinouts of these connectors can be found in the following sections.
Co n n e c to r Typ e La b e l
Audio jack (mic, line-out) Audio jack JAUDIO1
Ethernet and USB2.0 connectors RJ-45, USB 2.0
port
USBLAN1,
USBLAN2
Power connector 3-pin DC jack DC_IN1
RS-232/422/485 serial port connectors DB-9 COM12
RS-232 serial port connectors DB-9 COM34,
COM56,COM78
RS-232 serial port connectors DB-78 CN2
USB 2.0 connectors USB 2.0 port USB56
VGA connector DB-15 VGA1
Table 4-15: Rear Panel Connectors
4.3.1 Au d io J a c k (J AUDIO1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 LMIC1-L
3 GND 4 MIC1_JD
5
LMIC1-R
22
LINE_OUTL
23 GND 24 LINE1_JD
25 LINE1_JD
Table 4-16: Audio Jack Pinouts (JAUDIO1)
4.3.2 Eth e rn e t a n d US B2.0 Co n n e c to rs (US BLAN1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
P1 NC P2 LAN1_MDI0+
P 3 LAN1_MDI0- P 4 LAN1_MDI1+
