IEI Integration TANK-600-D2550_N2600 - Manual (Page 15)

TANK-600 Em b e d d e d S ys te m
P a g e 4
S p e c ific a tio n s
Mo th e rb o a rd
CP U Intel® dual core™ D2550 1.86 GHz processor
(TANK-600-CV-D2550-R10)
Intel® dual core™ N2600 1.6 GHz processor
(TANK-600-CV-N2600-R10)
Ch ip s e t Intel® NM10
S ys te m Me m o ry On-board DDR3 4GB (TANK-600-CV-D2550-R10)
On-board DDR3 2GB (TANK-600-CV-N2600-R10)
S to ra g e
Ha rd Drive 1 x 2.5’’ SATA HDD Bay
I/O in te rfa c e s
US B 2.0 6 x USB2.0
Eth e rn e t 2 x RJ-45 Realtek 8111E GbE LAN
RS -232 Default: 6 x DB-9
Optional: 8 x RS-232 by DB-78
RS -232/422/485 2 x DB-9
Dis p la y 1 x VGA
Re s o lu tio n Up to 2048 x 1536 @ 75Hz
Au d io 1 x Line-out, 1 x Mic-in
Expansions
P CIe Min i 1 x Full Size (Support mSATA)
1 x Half Size
Power
P o we r In p u t DC Jack: 9~36V DC
P o we r Co n s u m p tio n 12V @ 2.1A
Reliability
Mo u n tin g VESA 100, DIN-Rail
