WAFER-945GSE2 User Manual
Page 60
5.1.2 Installation Checklist
The following checklist is provided to ensure the WAFER-945GSE2 is properly installed.
All the items in the packing list are present
A compatible memory module is properly inserted into the slot
The CF Type I or CF Type II card is properly installed into the CF socket
The jumpers have been properly configured
The WAFER-945GSE2 is inserted into a chassis with adequate ventilation
The correct power supply is being used
The following devices are properly connected
o SATA drives
o Power supply
o USB cable
o Serial port cable
o Keyboard and mouse cable
The following external peripheral devices are properly connected to the
chassis:
o RS-232 serial communications device
o VGA screen
o USB devices
5.2 Unpacking
When the WAFER-945GSE2 is unpacked, please check all the unpacking list items listed
in Chapter 3 are indeed present. If any of the unpacking list items are not available please
contact the WAFER-945GSE2 vendor reseller/vendor where the WAFER-945GSE2 was
purchased or contact an IEI sales representative.
5.3 CF Card Installation
5.3.1 CF Card Installation
NOTE:
The WAFER-945GSE2 can support both CF Type I cards and CF Type
