WAFER-945GSE2 User Manual
Page 108
Disabled USB function disabled
Enabled D EFAULT USB function enabled
USB2.0 Controller Mode [HiSpeed]
The USB2.0 Controller Mode BIOS option sets the speed of the USB2.0 controller.
FullSpeed The controller is capable of operating at full speed
12 Mb/s
HiSpeed D EFAULT The controller is capable of operating at high speed
480 Mb/s
Legacy USB Support [Enabled]
Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard
support.
Normally if this option is not enabled, any attached USB mouse or USB keyboard does not
become available until a USB compatible operating system is fully booted with all USB
drivers loaded. When this option is enabled, any attached USB mouse or USB keyboard
can control the system even when there is no USB driver loaded onto the system.
Disabled Legacy USB support disabled
Enabled D EFAULT Legacy USB support enabled
Auto Legacy USB support disabled if no USB devices are
connected
6.4 PCI/PnP
Use the PCI/PnP menu (
884H881H
BIOS Menu 14) to configure advanced PCI and PnP settings.
WARNING:
Setting wrong values for the BIOS selections in the PCIPnP BIOS
