WAFER-945GSE2 User Manual
Page 5
Display
Intel® Generation 3.5 integrated GFX core (133 MHz)
18-bit dual channel LVDS integrated in Intel® 945GSE
Dual-display supported (VGA and LVDS)
BIOS AMI BIOS label
Audio Realtek ALC655 AC'97 codec
LAN Two Realtek RTL8111CPP GbE controllers
COM
One RS-232 serial port
One RS-232/422/485 serial port connector
USB2.0
Six USB 2.0 devices supported:
Four by onboard pin-headers
Two by external connectors
SATA Two 1.5 Gbps SATA drives supported
Keyboard/mouse One internal pin-header connector
Expansion One PC/104 ISA slot (ISA DMA Mode not supported)
Digital I/O
One 8-bit digital input/output connector; 4-bit input/4-bit output
through the ITE IT8718 super I/O
Watchdog Timer
Software programmable 1-255 sec. through the ITE IT8718
super I/O
Power Supply
5.0 V only
12 V for LCD/System Fan
AT and ATX support
Power Consumption
5V @ 3.1 A (1.6 GHz Intel® Atom™ with onboard 1.0 GB
DDR2 SDRAM)
Temperature 0ºC – 60ºC (32ºF - 140ºF)
Humidity (operating) 5%~95% non-condensing
Dimensions (LxW) 146 mm x 102 mm
Weight (GW/NW) 700g/230g
Table 1-1: Technical Specifications
