WAFER-945GSE2 User Manual
Page 47
PIN Description PIN Description PIN Description PIN Description
A12 SA19
A28 SA3
B12 -SMEMR
B28 BALE
A13 SA18
A29 SA2
B13 -IOW
B29 VCC
A14 SA17
A30 SA1
B14 -IOR
B30 ISAOSC
A15 SA16
A31 SA0
B15 -DACK3
B31 GND
A16 SA15
A32 GND
B16 DRQ3
B32 GND
Table 4-13: PC/104 Connector Pinouts (1 of 2)
PIN Description PIN Description PIN Description PIN Description
C1
GND
C11 -MEMW
D1
GND
D11 -DACK5
C2
-SBHE
C12 SD8
D2
-MEMCS16
D12 DRQ5
C3
SA23
C13 SD9
D3
-IOCS16
D13 -DACK6
C4
SA22
C14 SD10
D4
IRQ10
D14 DRQ6
C5
SA21
C15 SD11
D5
IRQ11
D15 -DACK7
C6
SA20
C16 SD12
D6
IRQ12
D16 DRQ7
C7
SA19
C17 SD13
D7
IRQ15
D17 VCC
C8
SA18
C18 SD14
D8
IRQ14
D18 -MASTER
C9
SA17
C19 SD15
D9
-DACK0
D19 GND
C10 -MEMR
C20 NC
D10 DRQ0
D20 GND
Table 4-14: PC/104 Connector Pinouts (2 of 2)
4.3.12 PC/104 Power Input Connector
CN Label:
CN1
CN Type:
3-pin wafer (1x3)
CN Location:
CN Pinouts:
The PC/104 power input connector provides power to the PC/104 expansion module
installed on the PC/104 slot.
