Disabled No base address is assigned to serial port 6
3E8 Serial port 6 I/O port address is 3E8
2E8 Serial port 6 I/O port address is 2E8
2F0 Serial port 6 I/O port address is 2F0
2E0 D EFAULT Serial port 6 I/O port address is 2E0
Serial Port6 IRQ [11]
Use the Serial Port6 IRQ option to select the interrupt address for serial port 6.
10 Serial port 6 IRQ address is 10
11 D EFAULT Serial port 6 IRQ address is 11
5.3.4 Hardware Health Configuration
The Hardware Health Configuration menu (BIOS Menu 7) shows the operating
temperature, fan speeds and system voltages.
BIOS SETUP UTILITY
Advanced
Hardware Health Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU FAN Mode Setting [Full On Mode]
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU Temperature :43ºC/109ºF
System Temperature :33ºC/91ºF
CPU Fan Speed
:N/A
CPU Core
:1.136 V
+1.05V :1.040 V
+3.30V :3.296 V
+5.00V :4.972 V
+12.0V :12.288 V
+1.5V :1.477 V
+1.8V :1.792 V
5VSB :5.053 V
VBAT :3.184 V
Fan configuration mode
setting
Select Screen
↑ ↓ Select
Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Hardware Health Configuration
