IMBA-C604EN ATX Mo th e rb o a rd
P a g e 76
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Configuration
Intel(R) Pentium(R) CPU 1407 @ 2.80GHz
CPU Signature
206d6
Microcode Patch 615
Max CPU Speed 2800 MHz
Min CPU Speed 1200 MHz
Processor Cores 2
Intel HT Technology Not Supported
Intel VT-x Technology Supported
L1 Data Cache
32 kB x 2
L1 Code Cache 32 kB x 2
L2 Cache 256 kB x 2
L3 Cache 5120 kB
----------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 7: CPU Information
The CPU Information submenu (BIOS Menu 7) lists the following CPU details:
 Processor Type: Lists the brand name of the CPU being used
 CPU Signature: Lists the CPU signature value.
 Microcode Patch: Lists the microcode patch being used.
 Max CPU Speed: Lists the maximum CPU processing speed.
 Min CPU Speed: Lists the minimum CPU processing speed.
 Processor Cores: Lists the number of the processor core
 Intel HT Technology: Indicates if Intel HT Technology is supported by the
CPU.
 Intel VT-x Technology: Indicates if Intel VT-x Technology is supported by the
CPU.
 L1 Data Cache: Lists the amount of data storage space on the L1 cache.
 L1 Code Cache: Lists the amount of code storage space on the L1 cache.
 L2 Cache: Lists the amount of storage space on the L2 cache.
 L3 Cache: Lists the amount of storage space on the L3 cache.
5.3.5 Ru n tim e Erro r Lo g g in g
The Runtime Error Logging menu (BIOS Menu 8) configures runtime error logging
support function.
