IMBA-C604EN ATX Mo th e rb o a rd
P a g e 7
1.7 Te c h n ic a l S p e c ific a tio n s
IMBA-C604EN technical specifications are listed below.
S p e c ific a tio n /Mo d e l IMBA-C604EN
Form Factor ATX
CPU LGA1356 socket supports Intel® Xeon® E5-2400 series processor
with up to eight cores
System Chipset Intel® C604
Graphics Engine ASPEED AST1300
PCIe VGA/2D controller, 1920x1200@60Hz 32bpp
Display Output Driver form AST1300
Memory Six 240-pin 1600/1333MHz dual-channel DDR3 SDRAM sockets
supported ECC UDIMMs or non-ECC RDIMMs/LRDIMMs (system
max. 48GB UDIMMs/96GB RDIMMs/192GB LRDIMMs)
Audio Realtek ALC662 HD Audio Codec (Line-out, Mic)
BIOS UEFI BIOS
Digital I/O 8-bit Digital I/O (8-bit GPIO is for programming I/O)
Ethernet Dual Intel® 82574L PCIe controller
Super I/O Controller Fintek F81866
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion
PCI Two PCI slots
PCIe Three PCIe x8 slots
One PCIe x4 slot
I/O Interface Connectors
Audio Connectors Two external audio jacks (line-out, mic-in)
Display port One VGA port
Ethernet Two RJ-45 GbE ports
Keyboard/Mouse Dual PS/2 port
