IMBA-C604EN ATX Mo th e rb o a rd
P a g e 16
3.1.2 P e rip h e ra l In te rfa c e Co n n e c to rs
The table below lists all the connectors on the board.
Co n n e c to r Typ e La b e l
ATX power connector 24-pin ATX ATX1
Battery connector battery holder BAT1
Chassis intrusion connector 2-pin wafer CASE_OPEN1
CPU power connector 8-pin Molex CPU12V1
DDR3 DIMM slots DDR3 DIMM slot DIMMA1
DIMMA2
DIMMB1
DIMMB2
DIMMC1
DIMMC2
Digital I/O connector 10-pin header DIO1
Fan connectors (system) 4-pin wafer SYS_FAN1
SYS_FAN2
Fan connector (system) 3-pin wafer SYS_FAN3
SYS_FAN4
Fan connector (CPU) 4-pin wafer CPU_FAN1
Front panel audio connector 10-pin header FP_AUDIO1
Front panel connector 14-pin header F_PANEL1
I2C connector 4-pin wafer I2C_1
PCI slots PCI slots PCI1, PCI2
PCIe x4 slot PCIe x4 slot PCIEX4_SLOT1
PCIe x8 slots PCIe x8 slot PCIEX8_ SLOT1
PCIEX8_ SLOT2
PCIEX8_ SLOT3
