IMBA-C604EN ATX Mo th e rb o a rd
P a g e 17
Co n n e c to r Typ e La b e l
SAS 3Gb/s drive connector 7-pin SAS connector SAS1, SAS2
SAS3, SAS4
SAS LED connector 4-pin wafer SAS_LED1
SAS SMBus connector 4-pin wafer SAS_SMBUS1
SATA 3Gb/s drive connector 7-pin SATA connector SATA3, SATA4
SATA 6Gb/s drive connector 7-pin SATA connector SATA1, SATA2
Serial port, RS-422/485 4-pin wafer COM2
Serial port, RS-232 40-pin box header COM3-6,
COM7-10
SMBus connector 4-pin wafer SMBUS_1
SPI ROM connector 6-pin header JSPI1
TPM connector 20-pin header TPM1
USB connectors 8-pin header USBAB1, USB3,
USB4
USB connector Type A connector USB12
Table 3-1: Peripheral Interface Connectors
3.1.3 Exte rn a l In te rfa c e P a n e l Co n n e c to rs
The table below lists the connectors on the external I/O panel.
Co n n e c to r Typ e La b e l
Audio connector Audio jack AUDIO_CV1
Ethernet and USB 2.0 ports RJ-45, USB 2.0 LAN2_USB01
Ethernet and USB 3.0 ports RJ-45, USB 3.0 LAN1_USB3_1
Keyboard and mouse connector Dual PS/2 KBMS1
USB 2.0 ports USB 2.0 USB1
VGA and serial port connector 15-pin female, DB-9 male VGA COM1
Table 3-2: Rear Panel Connectors
