IEI Integration IMBA-C604EN - Manual (Page 113)

IMBA-C604EN ATX Mo th e rb o a rd
P a g e 98
5.4.1 No rth Brid g e
Use the North Bridge menu (BIOS Menu 19) to configure the Northbridge chipset.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
ICH Configuration
Total Memory
4096 MB (DDR3)
Current Memory Mode
Independent
Current Memory Speed 1066 MHZ
Mirroring Not Possible
Sparing Not Possible
Memory Mode [Independent]
DRAM PAPL Mode [DRAM PAPL MODE1]
DIMM Information
Select the mode for
memory initialization.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 19: Northbridge Chipset Configuration
 Mem o ry Mo d e [In d ep en d en t]
Use the Memory Mode option to configure memory mode.

Independent DEFAULT Configures memory mode as independent mode.

Mirroring Configures memory mode as mirroring mode.

Lock Step Configures memory mode as lock step mode

Sparing Configures memory mode as sparing mode.
 DRAM PAPL Mo d e [DRAM PAPL MODE1]
Use the DRAM PAPL Mode option to configure DRAM PAPL mode.

Disable Disable DRAM PAPL mode.
