IMB-C2160 Mic ro -ATX Mo th e rb o a rd
P a g e 33
The SATA drive connectors can be connected to SATA drives and support up to 6Gb/s
data transfer rate.
Figure 3-18: SATA 3Gb/s Drive Connector Locations
Pin Description Pin Description
1 GND 2 TX
3 TX- 4 GND
5 RX- 6 RX
7 GND
Table 3-14: SATA 3Gb/s Drive Connector Pinouts
3.2.18 S e ria l P o rt Co n n e c to r, RS -422/485
CN La b e l: COM2
CN Typ e : 4-pin wafer
CN Lo c a tio n : See Figure 3-19
CN P in o u ts : See Table 3-15
This connector provides RS-422 or RS-485 communications.
