KINO-QM670 Mini-ITX SBC
Page 44
3.3.7 USB Connectors
CN Label: USB1, USB2
CN Type: USB port
CN Location: See
7
Figure 3-24
CN Pinouts: See
7
Table 3-32
The KINO-QM670 has four external USB 2.0 ports. The ports connect to both USB 2.0
and USB 1.1 devices.
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC (+5V) 5 DATA+
2 GND 6 DATA-
3 DATA- 7 GND
4 DATA+ 8 VCC (+5V)
Table 3-32: USB Port Connector Pinouts (USB1, USB2)
3.3.8 VGA Connector
CN Label: CRT1
CN Type: 15-pin Female
CN Location: See
7
Figure 3-24
CN Pinouts: See
7
Figure 3-29 and
7
Table 3-33
The KINO-QM670 has a single 15-pin female connector for connectivity to standard
display devices.
