Serial port connector (RS-422/485) 4-pin header COM3
SMBus connector 4-pin wafer CN5
SPDIF connector 5-pin header SPDIF1
SPI Flash connector 8-pin header JSPI1, JSPI2
TPM connector 20-pin header TPM1
USB connectors 8-pin header USB1, USB2
Table 3-1: Peripheral Interface Connectors
3.1.3 External Interface Panel Connectors
The table below lists the connectors on the external I/O panel.
Connector Type Label
Audio jacks Audio jack AUDIO_CV1
Ethernet and USB 3.0 connector RJ-45/USB LAN1_USB1
Ethernet and USB 2.0 connector RJ-45/USB LAN2_USB2
HDMI port HDMI Type A port HDMI1, HDMI2
Power connector (12V, power adapter) 4-pin power jack PWR1
RS-232 serial port DB-9 COM1
USB connectors USB port USB1, USB2
VGA connector 15-pin female CRT1
Table 3-2: Rear Panel Connectors
3.2 Internal Peripheral Connectors
The section describes all of the connectors on the KINO-QM670.
