5.3.7.2 FAN 2 Configuration
Use the FAN 2 Configuration submenu (BIOS Menu 12) to configure fan 2 temperature
and speed settings.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PC Health Status
SYS Smart Fan control [Auto Mode by PWM]
Temperature Bound 1 60
Temperature Bound 2 50
Temperature Bound 3 40
Temperature Bound 4 30
Segment 1 Speed (PWM) 100
Segment 2 Speed (PWM) 85
Segment 3 Speed (PWM) 70
Segment 4 Speed (PWM) 60
Segment 5 Speed (PWM) 50
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 12: FAN 2 Configuration
Î CPU Smart Fan control [Auto Mode by PWM]
Use the SYS Smart Fan control option to configure the system smart fan.
Î
Auto by RPM The fan adjusts its speed using Auto by RPM
settings
Î
Auto Mode by
PWM
D EFAULT The fan adjusts its speed using Auto by PWM
settings
Î
Manual by
RPM
The fan spins at the speed set in Manual Mode by
RPM settings
Î
Manual Mode
by PWM
The fan spins at the speed set in Manual by PWM
settings
