Î Temperature Bound n
Use the + or – key to change the fan Temperature Bound n value. Enter a decimal
number between 0 and 127.
Î Segment n Speed (PWM)
Use the + or – key to change the fan Segment n Speed value in Pulse Width Modulation
(PWM). Enter a decimal number between 0 and 100.
5.3.8 Serial Port Console Redirection
The Serial Port Console Redirection menu (BIOS Menu 13) allows the console
redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
COM0
Console Redirection [Disabled]
> Console Redirection Settings
COM1
Console Redirection [Disabled]
> Console Redirection Settings
COM2 (Pci Bus0, Dev22, Func3)
Console Redirection [Disabled]
> Console Redirection Settings
Serial Port for Out-of-Band Management/
Windows Emergency Management Services (EMS)
Console Redirection [Enabled]
> Console Redirection Settings
Console Redirection
Enable or Disable
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 13: Serial Port Console Redirection
Î Console Redirection [Disabled]
Use Console Redirection option to enable or disable the console redirection function.
