KINO-QM57A Mini-ITX SBC
Page 79
5.3.3 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 5) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Port0
Not Present
SATA Port1 Not Present
SATA Port2 Not Present
SATA Port3 Not Present
SATA Port4 Not Present
SATA Port5 Not Present
SATA Mode
[IDE Mode]
(1) IDE Mode. (2) AHCI
Mode. (3) RAID Mode.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
BIOS Menu 5: IDE Configuration
Î SATA Mode [IDE Mode]
Use the SATA Mode option to configure SATA devices as normal IDE devices.
Î
Disable Disables SATA devices.
Î
IDE Mode D EFAULT Configures SATA devices as normal IDE device.
Î
AHCI Mode Configures SATA devices as AHCI device.
Î
RAID Mode Configures SATA devices as RAID device.
