KINO-QM57A Mini-ITX SBC
Page 86
5.3.6 H/W Monitor
The H/W Monitor menu (BIOS Menu 9) shows the operating temperature, fan speeds and
system voltages.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+43 C
SYS Temperature :+49 C
CPU FAN Speed :4702 RPM
SYS FAN Speed :N/A
VCC3C :+3.312 V
V_core :+1.192 V
+5V :+5.045 V
+12V :+11.792 V
+1.5V :+1.504 V
VSB3V :+3.312 V
VBAT :+3.216 V
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
BIOS Menu 9: Hardware Health Configuration
Î PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ System Temperatures:
o CPU Temperature
o System Temperature
ƒ Fan Speeds:
o CPU Fan Speed
o System Fan Speed
ƒ Voltages:
o VCC3V
o Vcore
o +5V
