4.5.8 iTPM Enable Jumper (Reserved)

NOTE:

Intel® does not support iTPM function for Intel® QM57 chipset when

writing this manual. The iTPM Enable Jumper is reserved for future

use.

Jumper Label:

J_ITPM1

Jumper Type:

3-pin header

Jumper Settings:

See Table 4-9

Jumper Location:

See Figure 4-13

The iTPM enable jumper enables or disables the iTPM function. The iTPM enable jumper

settings are shown in Table 4-3.

Setting Description

Short 1-2

Disable iTPM

Short 2-3

Enable iTPM

Default

Table 4-9: iTPM Enable Jumper Settings (Reserved)
