C.2.5 Create Factory Default Image

NOTE:

Before creating the factory default image, please configure the system

to a factory default environment, including driver and application

installations.

To create a factory default image, please follow the steps below.

Step 1:

Turn on the system. When the following screen displays (

Figure A-2), press the

<F3> key to access the recovery tool. The message will display for 10 seconds,

please press F3 before the system boots into the operating system.

Figure C-10: Press F3 to Boot into Recovery Mode

Step 2:

The recovery tool menu appears. Type <4> and press <Enter>. (

Figure A-3)

Figure C-11: Recovery Tool Menu

Step 3:

The About Symantec Ghost window appears. Click OK button to continue.
