ICE-QM770 COM Express Module
Page 67
5.4.2 System Agent (SA) Configuration
Use the System Agent (SA) Configuration menu (BIOS Menu 23) to configure the
System Agent (SA) parameters.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
VT-d
[Disabled]
> Graphics Configuration
> NB PCIe Configuration
> Memory Configuration
Check to enable VT-d
function on MCH.
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 23: System Agent (SA) Configuration
VT-d [Disabled]
Use the VT-d option to enable or disable VT-d support.
Disabled D EFAULT Disables VT-d support.
Enabled Enables VT-d support.
5.4.2.1 Graphics Configuration
Use the Graphics Configuration (BIOS Menu 24) menu to configure the video device
connected to the system.
