ICE-QM770 COM Express Module
Page 18
Pin No. Description Pin No. Description
A65 PCIE_TX1- B65 PCIE_RX1-
A66 GND8 B66 WAKE0#
A67 GPI2 B67 WAKE1#
A68 PCIE_TX0+ B68 PCIE_RX0+
A69 PCIE_TX0- B69 PCIE_RX0-
A70 GND9 B70 GND22
A71 LVDS_A0+ B71 LVDS_B0+
A72 LVDS_A0- B72 LVDS_B0-
A73 LVDS_A1+ B73 LVDS_B1+
A74 LVDS_A1- B74 LVDS_B1-
A75 LVDS_A2+ B75 LVDS_B2+
A76 LVDS_A2- B76 LVDS_B2-
A77 LVDS_VDD_EN B77 LVDS_B3+
A78 LVDS_A3+ B78 LVDS_B3-
A79 LVDS_A3- B79 LVDS_BKLT_EN
A80 GND10 B80 GND23
A81 LVDS_A_CK+ B81 LVDS_B_CK+
A82 LVDS_A_CK- B82 LVDS_B_CK-
A83 LVDS_I2C_CK B83 LVDS_BKLT_CTRL
A84 LVDS_I2C_DAT B84 VCC5SBY1
A85 GPI3 B85 VCC5SBY2
A86 RSVD B86 VCC5SBY3
A87 RSVD B87 VCC5SBY4
A88 PCIE0_CK_REF+ B88 BIOS_DIS1#
A89 PCIE0_CK_REF- B89 VGA_RED
A90 GND11 B90 GND24
A91 SPI_VCC B91 VGA_GRN
A92 SPI_MISO B92 VGA_BLU
A93 GPO0 B93 VGA_HSYNC
A94 SPI_CLK B94 VGA_VSYNC
A95 SPI_MOSI B95 VGA_I2C_CK
A96 PP_TPM B96 VGA_I2C_DAT
