Manual Mode D EFAULT The fan spins at the speed set in Fan1/Fan2
expect PWM Output settings.
Fan1/ Fan2 expect PWM Output
Use the + or – key to change the value. Enter a decimal number between 0 and 255.
5.3.13 Serial Port Console Redirection
The Serial Port Console Redirection menu (BIOS Menu 18) allows the console
redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
COM1
Console Redirection [Disabled]
> Console Redirection Settings
COM2
Console Redirection [Disabled]
> Console Redirection Settings
iAMT SOL
COM3(Pci Bus0, Dev22,Func3)
Console Redirection [Disabled]
> Console Redirection Settings
Console Redirection
Enable or Disable
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 18: Serial Port Console Redirection
Console Redirection [Disabled]
Use Console Redirection option to enable or disable the console redirection function.
Disabled D EFAULT Disabled the console redirection function
Enabled Enabled the console redirection function
Terminal Type [ANSI]
Use the Terminal Type option to specify the remote terminal type.
