ICE-QM770 COM Express Module
Page 49
5.3.5 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
SATA Mode Selection
[IDE]
S_ATA1 Empty
S_ATA2 Empty
S_ATA3 Empty
S_ATA4 Empty
Determines how SATA
controller(s) operate.
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 7: SATA Configuration
SATA Mode Selection [IDE]
Use the SATA Mode Selection option to configure SATA devices.
IDE D EFAULT Configures SATA devices as normal IDE device.
AHCI Configures SATA devices as AHCI device.
RAID Configures SATA devices as RAID device.
NOTE:
Before accessing the RAID configuration utility, ensure to set the
Option ROM Messages BIOS option in the Boot menu to Force
BIOS. This is to allow the “Press to enter Configuration
Utility……” message to appear during POST. Press Ctrl+I when
prompted to enter the RAID configuration utility.
