ICE-QM770 COM Express Module
Page 64
5.4 Chipset
Use the Chipset menu (BIOS Menu 20) to access the PCH IO and System Agent (SA)
configuration menus.
WARNING!
Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu
may cause the system to malfunction.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
> PCH-IO Configuration
> System Agent (SA) Configuration
PCH Parameters
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 20: Chipset
5.4.1 PCH-IO Configuration
Use the PCH-IO Configuration menu (BIOS Menu 21) to configure the PCH parameters.
