ICE-QM770 COM Express Module
Page 59
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
FAN1 : N/A
FAN2 : N/A
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 16: W83627DHG H/W Monitor
5.3.12.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 17) to configure fan
temperature and speed settings.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
FAN1 Smart Fan Mode [Manual Mode]
Fan1 expect PWM Output 255
FAN2 Smart Fan Mode
[Manual Mode]
Fan2 expect PWM Output 255
FAN1 Smart Fan Mode
Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 17: Smart Fan Mode Configuration
FAN1/FAN2 Smart Fan Mode [Manual Mode]
Use the FAN1/FAN2 Smart Fan Mode option to configure the system smart fans.
