PCISA-945GSE CPU Card
Page 55
LCD Panel
Selection
Description
Open
640 x 480 (18-bit)
1-2
800 x 480 (18-bit)
3-4
800 x 600 (18-bit)
1-2 and 3-4
1024 x 768 (18-bit)
5-6
1280 x 1024 (36-bit)
1-2 and 5-6
1400 x 1050 (36-bit)
3-5 and 5-6
1400 x 900 (36-bit)
1-2, 3-4 and 5-6
1600 x 1200 (36-bit)
Table 4-6: LCD Panel Type Selection Jumper Settings
4.7.6 LVDS Voltage Selection
WARNING:
Permanent damage to the screen and PCISA-945GSE may occur if the
wrong voltage is selected with this jumper. Please refer to the user
guide that came with the monitor to select the correct voltage.
Jumper Label:
J_VLVDS1
Jumper Type:
3-pin header
Jumper Settings:
See Table 4-7
Jumper Location:
See Figure 4-4
The LVDS Voltage Selection jumper allows the LVDS screen voltage to be set. The
LVDS Voltage Selection jumper settings are shown in Table 4-7.
LCD Voltage Select
Description
1-2
3.3 V
2-3
5 V
Table 4-7: LVDS Voltage Selection Jumper Settings
