PCISA-945GSE CPU Card
Page 54
The CF Card Setup jumper sets the CF Type I card or CF Type II cards as either the slave
device or the master device. CF Card Setup jumper settings are shown in Table 4-4.
CF Card Setup Description
Open Slave
Closed Master
Table 4-4: CF Card Setup Jumper Settings
4.7.4 COM2 RS-232/422/485 Selection Jumper
Jumper Label: JP1
Jumper Type: 8-pin header
Jumper Settings: See Table 4-5
Jumper Location: See Figure 4-4
The RS-232/422/485 Serial Port Select jumper sets the communication protocol used by
COM3. The RS-232/422/485 Serial Port Select settings are shown in Table 4-5.
RS-232/422/485 Description
1-2 RS-232
3-4 RS-422
5-6 RS-485
7-8 RS-485 with RTS Control
Table 4-5: COM2 RS-232/422/485 Selection Jumper Pinouts
4.7.5 LCD Panel Type Selection
Jumper Label: J_LCD_TYPE1
Jumper Type: 6-pin header
Jumper Settings: See Table 4-6
Jumper Location: See Figure 4-4
The LCD Panel Type Selection jumper allows the LVDS screen voltage to be set. The
LCD Panel Type Selection jumper settings are shown in Table 4-7.
