34
IEI ® Technology, Corp.
Supports Power-Off CD function
Adjustable VREFOUT control
Supports 48KHz S/PDIF output, complying with AC'97 Rev 2.3 specifications
Supports 32K/44.1K/48KHz S/PDIF input
Power support: Digital: 3.3V; Analog: 3.3V/5V
Standard 48-pin LQFP package
EAX™ 1.0 & 2.0 compatible
Direct Sound 3D™ compatible
A3D™ compatible
I3DL2 compatible
HRTF 3D positional audio
10-band software equalizer
Voice cancellation and key shifting in Karaoke mode
2.16 Power Consumption
Table 2-1 shows the power consumption parameters for the ROCKY-3786EV CPU board
when a Pentium® III processor with a clock speed of 1GHz is running with a 256MB DDR
module.
Voltage Current
+5V 7.6A
+12V 0.23A
Table 2-1: Power Consumption
2.17 Packaged Contents and Optional Accessory Items
2.17.1 Package Contents
The ROCKY-3786EV is shipped with the following components.
1 x ROCKY-3786EV single board computer
1 x ATA66/100 flat cable
2 x SATA cable
1 x SATA power cable
1 x RS232 cable
