ZOLL M Series CCT
1
The M Series CCT
Introduction
The M Series CCT is an M Series unit with integrated features that provide additional display
capabilities. The following sections describe the additional features. A typical M Series CCT front
panel is shown in Fig. 1.
Figure 1: M Series CCT
NOTE: Refer to Section 2 of the M Series Operator’s Guide for the controls available on both the
M Series and the M Series CCT.
M Series CCT Option
In addition to the standard M Series features, the M Series CCT option can do the following:
• Display three traces simultaneously (Trace 1 is always ECG).
• Select which traces display in addition to ECG.
• Connect to an external VGA display (this feature is optional, only available through special
order).
• Configure displayed parameters by color.
IBP Channel 2
Connector
IBP Channel 1
Connector
NIBP
Connector
Temperature
Connector
VGA
Connector
(optional)
Contrast
Button
Softkey
