Configuring displayed parameters by color – ZOLL M Series CCT Defibrillator Rev E User Manual
Page 12
6
ZOLL M Series CCT
Configuring Displayed Parameters by Color
The M Series CCT allows you to select the colors used to display numerics and waveforms
associated with each physiological parameter (e.g.: ECG, SpO
2
, EtCO
2
, NIBP, Invasive pressure 1
and pressure 2, Temperature, etc.).
The parameter display colors available are Red, Cyan, Purple, Blue, Green, Yellow, and White.
Parameter display colors are factory configured as indicated below.
To reconfigure a parameter’s display color, please refer to the M Series CCT Configuration Guide.
Parameter
Color
ECG
Green
SpO
2
Yellow
EtCO
2
Blue
NIBP White
Temp
Purple
P1
Red
P2
Cyan
ART
Red
PA
Yellow
CVP
Cyan
ICP
White
