Assembly Instructions for WHSC-3/KD
12
ITEM
QTY
PART NUMBER
1
1
Side frame
2
1
Sideframe1
3
4
RollerAssy
4
12
1/4-20 Wing Nut- UNC
5
2
Spreader-Outer 20 in
6
1
Spreader-Inner 20-250 in
7
6
Bolt-Spreader Assy
8
3
Film Axle
9
3
Axle Pin End Cap
10
3
Axle Wing End Cap
11
1
WHSS-3-Sani Sir
12
6
Screw-PH-Figd-10-32 x 1-25
13
6
Nut- Elas-Stop-10-32
PARTS LIST
