Win-Holt ALC Series User Manual
Acks, Pizza pan racks, Channel pan racks

P
AGE
11
800.444.3595 I 516.921.0538 fax I www.winholt.com
R
A
CKS
Pizza Pan Racks
Our Pizza Pan Rack is ideal for storage, bussing and
transporting 17" and 19" diameter round pizza pans or 16"
and 17" square Sicilian pizza pans.
Durable, aluminum, all welded construction for rigidity and
strength with Heavy Duty angle slides.
Rolls easily on heavy duty 5" polyurethane
stem casters, front casters with brake.
Channel Pan Racks
Ideal for high and low profile products. General storage
and transporting of 18" x 26" trays and pans. “C”
Channel holds pans securely on lip.
Constructed of extra heavy duty, all welded 1" square
aluminum. Channels are ½" deep. Channel runners
are 1½" apart.
End Load Holds (1) 18” x 26” Full Sheet Pans
Side Load holds (2) 18” x 14” Half Sheet Pans
Rolls easily on four 5" heavy duty, swivel stem casters.
C-Channel
holds lip of tray
Model
Number
Order#
Overall Dimensions
Pan
Cap.
Runner
Spacing
Approx.
Ship Wt
Width
Length
Height
(in) (mm) (in) (mm) (in) (mm) 18”x26”
(lb)
(kg)
(lb)
(kg)
ALC-1836 110648
21
533
27
686
64 1,626
36
1½
38
40
18
ALC-1840 110672
40
42
19
Caster Information
757
123684
Swivel Square Stem Caster with 5" Polyurethane Wheel
7112
122180
5" Polyurethane Wheel
B
ETTER
M
EDIUM
D
UTY
U
SE
L
IFE
W
ARRANTY
A
GAINST
R
UST
Equipment Guide
Model
Number Order#
Overall Dimensions
# of
Pans
Runner
Spacing
Approx.
Ship Wt
Width
Length
Height
(in)
(mm)
(in)
(mm)
(in)
(mm)
(lb)
(kg)
(lb)
(kg)
PPR-13 206818
22
559
20
508
34
864
13
2
51
38
17
PPR-26 206826
62½ 1,588 26
53
24
Caster Information
757BK 206931
Swivel Square Stem Caster with Polyurethane Wheel and Brake
757
123684
Swivel Square Stem Caster with 5" Polyurethane Wheel
7112
122180
5" Polyurethane Wheel
B
ETTER
M
EDIUM
D
UTY
U
SE
L
IFE
W
ARRANTY
A
GAINST
R
UST
Equipment Guide
Freight Class: 250
Freight Class: 250
In line with our policy to continually improve our products, Win-Holt reserves the
right to change materials and specifications without notice.
