Wire Pan Racks
Wire pan racks are ideal for cooling, transporting, storing
and proofing.
Holds 18" x 26" aluminum pans and plastic trays.
End Load Holds (1) 18” x 26” Full Sheet Pans
Side Load Holds (2) 18” x 14” Half Sheet Pans
Pan slides spaced 1½" apart allow for a variety of high
and low profile products.
Mobile work stations have an ideal working height of 32”,
ideal for food preparation and storage.
Constructed of chrome steel wire pan slides secured to an
aluminum frame. 8" clearance from base of unit to floor.
Maneuvers easily on four 5" heavy duty polyurethane
swivel stem casters.
Donut Screen Rack
Ideal for proofing and transporting donuts.
Designed to hold (20) 23" x 23" standard donut screens
or (20) 24" x 24" glazing screens.
Constructed of 1" all welded heavy duty aluminum square
tubing and angle slides, runners spaced 3" apart.
Maneuvers easily on four 5" polyurethane swivel stem
casters.
WP-1830D/PT
Model
Number
Order#
Overall Dimensions
Approx.
Ship Wt
Width
Length
Height
(in)
(mm)
(in)
(mm)
(in)
(mm)
(lb)
(kg)
AL-2424B
110226
27
686
24
610
70
1,772
43
19
Caster Information
757
123684
Swivel Square Stem Caster with 5" Polyurethane Wheel
7112
122180
5" Polyurethane Wheel
Model
Number
Order#
Overall Dimensions
Pan
Cap.
Approx.
Ship Wt
Width
Length
Height
(in)
(mm)
(in)
(mm)
(in)
(mm)
18”x26”
(lb)
(kg)
WP-1836B
111034
21
533
24
610
68 1,727
36
67
30
WP-1815 / PPT 110947
25
635
32
813
15
47
21
WP-1830D / PT 110998
46
1,168
30
74
34
Caster Information
757
123684
Swivel Square Stem Caster with 5" Polyurethane Wheel
7112
122180
5" Polyurethane Wheel
B
ETTER
M
EDIUM
D
UTY
U
SE
L
IFE
W
ARRANTY
A
GAINST
R
UST
Equipment Guide
B
ETTER
M
EDIUM
D
UTY
U
SE
L
IFE
W
ARRANTY
A
GAINST
R
UST
Equipment Guide
WP-1815D/PT
Freight Class: 250
Freight Class: 250
Pan Rack Tray Direction Guide
End
Load
Side
Load
Double
Side Load
18”
Trays on page 116
26”
14”
18”
26”
18”
