Roll - In Refrigerator Racks
For storage and transportation of pans in and from
refrigerators.
Durable, aluminum, all welded construction for rigidity
and strength with Heavy Duty angle slides.
All models maneuver easily on easily on heavy duty 5"
polyurethane plate casters.
Model
Number
Order#
Overall Dimensions
# of
Pans
Runner
Spacing
Approx.
Ship
Weight
Width Length Height
(in) (mm) (in) (mm) (in) (mm) (lb) (kg)
ALREF-1118 / 64E 384956
20 7 /
8 530 26 660 64¼ 1,632
11 5 40 18
ALREF-1818 / 64E 384981 18 3 53 24
AL-1818B 109989 21 533 26 660 65 1,651 18 3 42 19
Caster Information
757 123684 Swivel Square Stem Caster with 5" Polyurethane Wheel
7112 122180 5" Polyurethane Wheel
AL-1816-IR-KD
AL-1807-IR-KD
Model
Number
Order#
Overall Dimensions
Cap
Tray
18x26
Runner
Spacing
Approx.
Ship Wt.
Width Length Height
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (lb) (kg)
AL-1807-IR-KD 626089 20 3/8 518 24 610 23 584 7" 3 76 14 6
AL-1816-IR-KD 582928 20 3/8 518 24 610 51 1295 16" 3 76 28 13
Reach - In Refrigerator
Insert Racks
Great for storing sheet pans in reach-in refrigerator
and freezers.
Constructed of all welded aluminum with 1-1/2” wide angle
slides.
Designed to hold 18: x 26” and 14x 18” trays.
End Load Holds (1) 18” x 26” Full Sheet Pans
Side Load holds (2) 18” x 14” Half Sheet Pans
Incredible savings over insert runners.
Low cube item for warehouses.
Ships knock down for added freight savings!
L
IGHT
D
UTY U SE
E
XPORT
L IFE W ARRANTY
A GAINST R UST
NEW
E
XPRESS
S
HIP
Equipment Guide
Freight Class: 100
L IGHT D UTY U SE
L
IFE
W
ARRANTY
A GAINST R UST
Equipment Guide
Freight Class: 250
