Win-Holt 550 Series User Manual
Aterial, Andling, Quipment

P
AGE
101
800.444.3595 I 516.921.0538 fax I www.winholt.com
M
A
TERIAL
H
ANDLING
E
QUIPMENT
Model
Number
Order#
Feature
Overall Dimensions
Capacity
Approx.
Ship Wt.
Width
Length
Height
(in) (mm) (in) (mm) (in) (mm) (lb) (kg) (lb) (kg)
550
100722
6 Rubber Wheels
18 457 51 1,295 37 940 700 318
78 35
550HD
100757
HD Rubber Wheels
550HD / SX 100765
HD Rubber Wheels,
Shelf & Tool Tray
80 36
Caster Information
711
122155
6" x 2" Mold-On Rubber Wheel
⎯
738
123246
Swivel Plate Caster with 5" x 1
¼
" Rubber Wheel
⎯
718
122690
5" x 1
¼
" Rubber Wheel
⎯
Ladder Truck
Utility Carts
All purpose truck is ideal for stocking, marking and
reaching high shelves.
Constructed or all welded steel with six wheel design for
maximum maneuverability. Non-skid steps and handle
bars assure secure grip and foot control.
Maneuvers easily on four 5” swivel rubber and two 5”
rigid rubber plate casters.
All welded angle iron steel construction stands up to
heavy duty applications.
Rounded front corners with two front bumpers protect
store fixtures and doors.
Retractable shelf is convenient for marking and packing out.
Recessed tool tray is built into the handle.
Standard color is blue.
550 series maneuvers easily on six wheels - four 5” rubber
swivel plate casters and two heavy duty 6” rubber center wheels.
Model
Number
Order#
Overall Dimensions
Capacity
Approx.
Ship Wt
Width
Length
Height
(in)
(mm)
(in)
(mm)
(in)
(mm)
(lb)
(kg)
(lb)
(kg)
LT-2
126252
24
610
50 1,270 53 1,346 1,000 454 140
63
Replacement Caster Information
743
123422
Rigid Plate Caster with 5" Rubber Wheel
⎯
738
123246
Swivel Plate Caster with 5" Rubber Wheel
⎯
718
122690
5" Rubber Wheel
⎯
Freight Class: 150
LT-2
550 Series
Option:
Specify options by adding suffix to Model Number listed below.
BP-2 (180902)...Bumpers (2)
B
EST
H
EAVY
D
UTY
U
SE
Equipment Guide
B
EST
H
EAVY
D
UTY
U
SE
Equipment Guide
Wagon Customer Cart with Plastic Deck
Rustproof green structural foam plastic deck wagon is ideal
for outdoor use.
Powder coated green steel frame. Handle returns to upright
position when released, with comfortable rubber grip on
handle.
Semi-pneumatic wheels (2) 6” x 2” rigid plate casters and (2)
swivel plate casters.
Model
Number
Order#
Overall Dimensions
Capacity
Approx.
Ship Wt
Width
Length
Height
(in) (mm)
(in)
(mm)
(in)
(mm)
(lb)
(kg)
(lb)
(kg)
W-2437PL/PA
217197
22
1/2
571
36
914
10
1/4
260
1200 534
50
23
Caster Information
7429
184680
Rigid Caster with 6” x 2” Semi-Pneumatic Wheel
7329
123166
Swivel Caster with 6” x 2” Semi-Pneumatic Wheel
7152
181593
6” x 2” Semi-Pneumatic Wheel
B
EST
H
EAVY
D
UTY
U
SE
Equipment Guide
Freight Class: 150
Freight Class: 92.5
W-2437PL/PA
