800.444.3595 I 516.921.0538 fax I www.winholt.com
These versatile aluminum pan racks will proof, store
and transport full size sheet pans or half size sheet
pans.
Constructed of all welded 1" heavy duty aluminum
tubing.
End Load Holds (1) 18” x 26” Full Sheet Pans
or (2) 18” x 14” Half Sheet Pans
Reinforced heavy duty solid cross braces.
All welded heavy duty, ½" angle supports.
Rolls easily on four 5" swivel stem casters.
Heavy Duty polyurethane wheels.
Shipped knock-down for extra freight savings!
Heavy Duty Knock-Down Pan Racks
Economy Knock-Down Pan Racks
These versatile aluminum pan racks will proof, store and
transport full size sheet
pans or half size sheet pans.
Constructed of all welded 1" aluminum tubing with heavy
duty, all welded angle pan supports.
End Load Holds (1) 18” x 26” Full Sheet Pans
or (2) 18” x 14” Half Sheet Pans
Rolls easily on four 5" swivel stem casters with polyolefin
wheels.
Shipped knock-down for extra freight savings!
Model
Number
Order#
Overall Dimensions
Pan
Cap.
Runner
Spacing
Approx.
Ship Wt.
Width
Length
Height
(in) (mm) (in) (mm) (in) (mm) 18”x26” (in)
(mm)
(lb)
(kg)
AL-1820KD / HD 323459 21 533 26 660 69 1,753 20
3
76
34
19
Caster Information
757
123684
Swivel Square Stem Caster with 5” Polyurethane Wheel
7112
122180
5" Polyurethane Wheel
Model
Number
Order#
Overall Dimensions
Pan
Cap.
Runner
Spacing
Approx.
Ship Wt.
Width
Length
Height
(in) (mm) (in) (mm) (in) (mm) 18”x26” (in)
(mm)
(lb)
(kg)
ADE1820B/KDA 112168 21 533 26 660 69
1,753
20
3
76
30
14
ADE1812B/KDA 127440 21 533 26 660 69
1,753
12
5
127
28
13
Caster Information
751
123588
Swivel Square Stem Caster with 5” Polyolefin Wheel
717
122681
5” Polyolefin Wheel
Freight Class: 100
G
OOD
L
IGHT
D
UTY
U
SE
E
XPORT
L
IFE
W
ARRANTY
A
GAINST
R
UST
E
XPRESS
S
HIP
Equipment Guide
UPS and the UPS brandmark are trademarks that are used with
permission by the owner, United Parcel Service of America, Inc.
All rights reserved.
Freight Class: 100
B
ETTER
L
IGHT
D
UTY
U
SE
E
XPORT
L
IFE
W
ARRANTY
A
GAINST
R
UST
E
XPRESS
S
HIP
Equipment Guide
Pan Rack Tray Direction Guide
End
Load
Side
Load
Double
Side Load
18”
Trays on page 116
26”
14”
18”
26”
18”
