Win-Holt AL-1810H_SSTOP User Manual
Acks, All welded half size pan racks, Heavy duty “built to last” pan racks

R
A
CKS
P
AGE
6
800.444.3595 I 516.921.0538 fax I www.winholt.com
All Welded Half Size Pan Racks
Half size pan racks for 18" x 26" and 14" x 18" pans and
trays.
Heavy duty Aluminum with welded angle slides.
Rolls easily on heavy duty 5" polyurethane swivel stem
casters.
Heavy Duty “Built to Last” Pan Racks
For transporting, storage of 18” x 26” pans.
Pan spacing 2”, 3” or 5” on stationary center.
Material: High tensile extruded 6063-T5 aluminum alloy.
All heli-arc welded aluminum construction
Pan Angle Guides: Extruded 1 “ x 2” x 0.100” thick .
Upright Frame: Constructed of extruded 1½” square tubing
Cross Braces: Extruded 1” Square tube cross member
welded to frame uprights.
Base: Manufactured from extruded angle to provide a
foundation of superior strength.
Casters: Easily maneuverable on four 5" diameter by 2”
wide polyurethane wheels.
Model
Number
Order#
Overall Dimensions
Pan
Cap.
Runner
Spacing
Approx.
Ship Wt.
Width
Length
Height
(in) (mm) (in) (mm)
(in)
(mm) 18”x26”
(in)
(mm)
(lb)
(kg)
AL-1806 / H
206797
21 533 26 660
38
955
6
5
127
21
10
AL-1810 / H
206800
10
3
76
23
10
AL-1810/H/SSTOP 626089
10
3
76
31
14
Caster Information
757
123684 Swivel Square Stem Caster with 5” Polyurethane Wheel
⎯
7112
122180
5" Polyurethane Wheel
⎯
Model
Number
Order#
Pan
Cap.
18” x 26”
Dimensions
Runner
Spacing
Approx.
Ship Wt.
Width
Length
Height
(in) (mm) (in) (mm) (in) (mm) (in)
(mm)
(lb)
(kg)
AL-1812/HD 592536
12
21½ 546
26
660
71½ 1,816
5
127
54
25
AL-1820/HD 592165
20
3
76
70
32
AL-1830/HD 592173
30
2
51
86
39
Replacement Caster Information
7318
123051
Swivel Plate Caster with 5" x 2” Polyurethane Wheel
M
EDIUM
D
UTY
U
SE
E
XPORT
L
IFE
W
ARRANTY
A
GAINST
R
UST
Equipment Guide
B
EST
H
EAVY
D
UTY
U
SE
C
ORRECTIONAL
L
IFE
W
ARRANTY
A
GAINST
R
UST
Equipment Guide
ST
Solid Top
SB
Solid Base
PEB
Perimeter Bumper
LB
“L” shape Bumper
VB
Vertical Bumper
(12”)
PP
Prison Package
Freight Class: 250
Freight Class: 250
Options:
Specify options by adding suffix to Model Numbers
B
Bumpers (4)
BP
Plate Casters 4” Rubber Wheel
LC
Locking Casters
TG-AL
Tray Guard/Aluminum
KD
Knock-Down Design
SB
Aluminum Solid Bottom
CORR
Correctional Package
Half Pan Rack with
Stainless Steel Top
AL-1810/HSSTOP
Options:
Specify options by adding suffix to Model Numbers
