51
• Adding and deleting untagged sets
• Sharing and unsharing VLANs
• Inserting and removing MAC addresses
• Toggling management access
To access the VLAN Management Menu, type v in the Configuration Menu. A screen similar to the following
will appear:
IntraCore 3524 VLAN Management Menu
VLAN Version: 1 VLAN Type: Port Based
Max. Supported VLAN ID: 4094 Max. Supported VLANs: 64
Number of VLANs Configured: 1 Number of Active VLANs: 1
v VLAN Group Static Configuration
p VLAN Port Attribute Configuration
d Display VLAN Groups Summary
a Display Port VLAN Attribute Summary
r Reset VLAN Configuration to Factory Default
q Return to previous menu
Command>
4.4.2 Configuring Static VLAN Groups
To access the VLAN Group Static Configuration Menu, type v in the Configuration Menu to access the
VLAN Management Menu, then type v again to access the VLAN Group Static Configuration Menu. A
screen similar to the following appears:
IntraCore 3524 VLAN Group Static Configuration Menu VID: [0002]
Name: test2 Created By: Mgmt
Mgm Access: Enable Status: Active
Unit Port List 1 8 9 16 17 24 25 32
====== ======== ======== ======== ========
1 -------- -------- -------- -KXXXXXX +: static
2 -------- -------- -------- KKXXXXXX d: dynamic
3 -------- -------- -------- KKXXXXXX -: Not Member
4 -------- -------- -------- KKXXXXXX K: Stacking
5 -------- -------- -------- KKXXXXXX
6 -------- -------- -------- KKXXXXXX
7 -------- -------- -------- KKXXXXXX
8 -------- -------- -------- KXXXXXXX
c Create VLAN r Remove VLAN
e Set VLAN Name t Toggle Mgmt Access
m Move ports to this VLAN d Delete Port Members
o Overlap Ports To This Vlan f Display Vlan-Grp Information
l Toggle To Vlan-prt Config Menu
Command>
S)elect VID N)ext VLAN P)rev VLAN H)elp Q)uit
Navigate to the VLAN that you want to configure by typing a command (s, n or p) as shown at the bottom of
the screen. With the Select command, you select a VLAN by its VLAN ID (VID); you can type the VID of an
existing VLAN, or the VID of a VLAN you will create.
