46
4.2 SNMP and RMON Management
The Simple Network Management Protocol (SNMP) may be used to manage the IntraCore 3524. The SNMP
agent supports database objects that are defined in the following management information bases (MIBs):
• MIB II (RFC 1213)
• Bridge MIB (RFC 1493)
• RMON (RFC 1757) 4 groups - Ethernet Statistics, Ethernet History, Alarm, and Events (See next
section for details)
• Private Asanté 3524 MIB
Any SNMP-based network management application can be used to manage the switch. For information on
management of switches, refer to your SNMP software manual. Also, see Chapter 6. SNMP Management
for more information on SNMP protocol.
For details on console-based SNMP settings, see “SNMP Configuration” in Chapter 3.
RMON Management
Remote Network Monitoring (RMON) allows the network manager to gather data on the network’s traffic for
future retrieval. RMON is an Internet Standard defined in RFC1757.
Using RMON, a network monitor (also called a probe) listens to traffic on the network and gathers statistics
that may be retrieved later by a network management station using SNMP, as described in the previous
section.
The four groups of RMON that are supported by the switch are described in Chapter 6. SNMP Management.
The IntraCore 3524 switches provide control of the RMON groups only through SNMP. For information on
controlling RMON groups, please refer to the documentation for your SNMP management application.
4.3 Security Management
To access the Security Management Menu, type t in the Configuration Menu. A screen similar to that below
will appear.
IntraCore 3524 Security Management Menu
Duplicated-IP Monitoring Status : Enable
Duplicated-IP Trap Status : Enable
Station Movement Trap Status : Disable
p Port Security Configuration
d Toggle Duplicated-IP Detection Enable/Disable
i Toggle Duplicated-IP Trap Enable/Disable
l Display Duplicated-IP List
s Toggle Station Movement Trap Enable/Disable
r Reset All Security Configuration to Factory Default
q Return to previous menu
Command>
Important! For any traps (alerts) to be sent, you must designate one or more devices as trap receivers. See
“SNMP Configuration” in Chapter 3.
4.3.1 Duplicated IP Detection and Trap
The duplicated IP detection and duplicated IP trap security measures allow you to monitor the use of a
single IP address by two stations.
If you enable duplicated IP detection, the switch starts monitoring the broadcast Address Resolution
Protocol (ARP) traffic from all of its ports, to detect duplicated IP address conditions. When duplicate IP
