2 Warner Electric Europe • +33 (0)2 41 21 24 24

P-2073-WE • 11/12

1

Technical specifications

1.1 Features


Units are delivered with “Z” dimension (see chart) factory set, for catalogue nominal
sliding torque : Cn ± 20% (Except specific requests for torque adjustment)).

Size

Table 1

50

100

200

400

800

1600

3200

6400

12800

N max.

RPM

«Z» dimension

mm

«Z max.» dimension

mm

VAR00 dimension

kg

VAR05 - E dimension

mm

VAR05 Weight

kg

4800

0.8

4

4.2

26

+2/0

9.7

3800

1.5

4

5.8

30

+2.2/0

9.7

3200

1.6

4

7.3

30

+2.2/0

18.1

2700

2.1

5

10.1

35

+2.6/0

24.4

2200

3

6.5

16.2

40

+3/0

36.8

1900

3.5
6.5

28.4

45

+3/0

61.4”

1600

2.9
6.5

37.4

45

+3.4/0

71.4

1300

3.7

8

75

55

+4.2/0

142

1000

4

11

162

75

+5.7/0

344

NB :

data for catalogue equipment .

Symbol designating
an action that might
damage the brake

Symbol designating an
action that might be
dan gerous to human safety

Symbol designating an
elec trical action that might be
dangerous to human safety

2

Precautions and restrictions on use

2.1

Restrictions on use


If maximum rotation speeds are exceeded, the guarantee is no longer valid.

2.2

Precautions in use and safety measures


During maintenance work, ensure that the mechanism to be driven by the units is at rest and that there is no
risk of it being started accidentally. All intervention have to be made by qualified personnel, owning this
manual.

We,

WARNER ELECTRIC EUROPE, 7, rue Champfleur, B.P. 20095, F-49182 St Barthélemy d’Anjou Cedex

declare that the torque limiters made in our factory from St Barthélemy d’Anjou,
and hereafter designated :

L331

are exclusively designed for incorporation into a machine and to be assembled with other equipments to create a machine. The operation of

the product is submitted to the conformity of the complete equipment, following the provisions of the machinery directive 98/37/EC.

Drawn up in St Barthélemy d’Anjou, July 2002 E.
PRAT, General Managing Director

CONTENTS

1

Technical specifications

2

1.1 Features

2

2

Precautions and restrictions on use

2

2.1 Restrictions on use

2

2.2 Precautions and safety measures

2-3

3

Installation

3

3.1 Transport - storage

3

3.3 Handling

3

3.4 Setting up

3

4

Maintenance

4

4.1 Maintenance

4

4.2 Dismantling / Reassembling

4

4.3 Spare parts

4

4.4 Important recommendations

4

5

Appendix

5

5.1 Drawings / Description VAR00

5

5.2 Drawings / Description VAR05

6
