Shopair parts list – Vestil ACH-100 User Manual
Page 16
K
Ke
ey
y N
No
o.. D
De
es
sc
crriip
pttiio
on
n
Q
Qtty
y..
P
Pa
arrtt N
No
o..
620-107
Main Frame
1
20352
620-108
Liftwheel Seal
1
20705
620-109
Protector Bearing, Main Frame Side
1
88636
620-111
Protector Assembly
500# (Single Reeved) & 1000# Units
1
20645
20665
620-112
Thrust Washer, Second Pinion
2
88640
620-113
Gear Housing
1
20350
620-114
Protector Bearing, Gear Housing
1
88636
620-115
First Pinion Bearing
1
88635
620-125
Pin Plate
1
20700
620-126
Pin Plate Screw
2
20743
620-127
Liftwheel and Gear Assembly
500# (Single Reeved) & 1000# Units
1
20664
20666
620-128
Liftwheel Bearing
2
88637
620-129
Thrust Washer, Liftwheel
2
88638
620-130
Liftwheel Shaft Seal
1
20704
620-131
First Pinion and Shaft
10 Tooth
12 Tooth
1
Contact
Factory
620-133
Spacer
2
20964
620-134
Gear Housing Screw
2
20384
620-135
Gear Housing Screw (short)
2
920718
620-136
Dowel Pin
4
920720
620-137
Upper Hook
1
20650
620-138
Hook Latch Kit
2
595522
620-139
Hook Retainer
1
20712
620-140
Hook Retainer Screw
1
920725
620-141
Chain Guide
1
20304
620-142
Chain Guide Pin
4
20729
620-143
Chain Stripper
1
20305
620-144
Load Chain (Specify Length Req’d.)
-
85988
620-145
Loose End Ring
1
20744
620-146
Chain Stop
2
20428
620-147
Chain Stop Screw
2
25848
620-147A Chain Stop Screw Nut
2
982472
620-148
Liftwheel Shaft
1
20313
620-149
Thrust Washer, First Pinion
2
88639
620-155
Caution Label
1
20758
620-156
Hook Block
2
20995
500#, 600# and 1000#
2
20739
620-157
Hook Block Screw
2
920730
500#, 600# and 1000#
2
920724
620-159
Hook (Includes 620-138)
1
23030
SHOPAIR PARTS LIST
K
Ke
ey
y N
No
o.. D
De
es
sc
crriip
pttiio
on
n
Q
Qtty
y..
P
Pa
arrtt N
No
o..
620-160
Dead End Plate
500#, 600# and 1000#
1
20714
620-161
Dead End Pin
500#, 600# and 1000#
1
920720
620-162
Sheave Wheel (Includes 620-164)
500#, 600# and 1000#
1
20652
620-163
Sheave Wheel Shaft
500#, 600# and 1000#
1
20318
620-164
Sheave Wheel Bearing
500#, 600# and 1000#
1
88641
620-165
Sheave Wheel Thrust Washer
500#, 600# and 1000#
2
88639
620-168
Dead End Plate Screw
500#, 600# and 1000#
2
73715
620-174 Gasket
1
20755
620-196 Hook Block Lockwasher
2
940802
Part Number for Packaged
Lubricants
Used in the ShopAir
(Refer to Page 6 for Lubrication Instructions)
Lubricant
Usage
Type
Lubricant
Part Numbers and
Packaged Quantity
of Lubricants
Hoist Gears
Grease
Century
Lubricants HB-11,#3
28605 for 1/2 lb. Can
28615 for 1 lb. Can
28617 for 4 lb. Can.
Spline one end of
First Pinion and Shaft
Oil-Graohite Mixture
Hercules Packing Co.
Moly-Duolube
40628 for 1 Pint Can
Load Chain
Oil
Friske Bros.
Lubriplate
®
Bar and
Chain Oil #10R
28608 for 1 Pint Can
28619 for 1 Gal. Can
Lower Hook Knob
Grease
Dow Corning
Molykote BR-2-S
28606 for 1/2 lb. Can
28618 for 1 lb. Can
When ordering lubricants, specify the type of lubricant, part
number and packaged quantity required.
11
