REV 1 CT-3500 S2 USER’S MANUAL
3
1.2 Technical Specifications
Table 1. CT-3500 S2 Technical Specifications
TYPE portable circuit-breaker analyzer
PHYSICAL SPECIFICATIONS 16”W x 7”H x 13” D (40.6 cm x 17.4 cm x 33 cm); Weight: 14 lbs. (6.4 Kg)
INPUT POWER 100-240 Vac, 50/60 Hz
DRY-CONTACT INPUT 3 channels
TRIGGER INPUT VOLTAGE open/close: 24-300 V, DC or peak AC
BREAKER OPERATIONS Open, Close, Open-Close, Close-Open
TIMING RESOLUTION ±0.1 millisecond; accuracy: 0.05% of reading ±0.1 ms
DISPLAY back-lit LCD screen (128 x 64 pixels); viewable in bright sunlight and low light
conditions
KEYPAD rugged, 44-key "QWERTY"-style membrane keypad
PRINTER built-in 2.5-inch wide thermal printer
INTERNAL TEST RECORD
STORAGE
stores up to 128 timing records
COMPUTER INTERFACE one USB PC interface, one USB Flash drive interface
PC SOFTWARE Windows®-based Breaker Analysis software included with purchase price
SAFETY designed to meet IEC61010 (1995), UL61010A-1, CSA-C22.2 standards
ENVIRONMENT Operating: -10°C to +50°C (+15°F to +122°F);
Storage: -30°C to +70°C (-22°F to +158°F)
HUMIDITY 90% RH @ 40°C (104°F) non-condensing
ALTITUDE 2,000 m (6,562 ft) to full safety specifications
CABLES furnished with full set of test leads (including 20-foot contact leads, 30-foot
contact lead extensions, trigger cable, power cable, and ground cable)
OPTIONS transportation case
WARRANTY one year on parts and labor
NOTE
The above specifications are valid at nominal operating voltage and at a
temperature of 25
°C (77°F). Specifications may change without prior notice.
