CT-3500 S2 USER’S MANUAL

REV 1

d. The following screen will be displayed:

Press the

[1]

key (YES) to print the test results on the unit’s built-in thermal printer.

NOTE

You can also view the test results on the unit’s LCD screen. Please see section
3.6.1.

e. The test results will be printed (please see Figure 8) and the following screen will be

displayed:

Press the [1] key (YES) to save the test shot.

NOTE

If a USB Flash drive is connected to the unit’s “USB MEM” port, the following
screen will be displayed:

1. SAVE INTERNALLY

Press the

[1]

key (SAVE INTERNALLY) to save the test shot to the unit’s

internal memory. Continue to step f.

2. SAVE TO THUMB DRIVE

Press the

[2]

key (SAVE TO THUMB DRIVE) to save the test shot to the

connected USB Flash drive. The test record will be saved and the following
screen will be displayed:

1.SAVE INTERNALLY
2.SAVE TO THUMB DRIVE

SAVE THIS SHOT?
1.YES
2.NO

PRINT TEST RESULTS?
1.YES
2.NO
