CT-3500 S2 USER’S MANUAL

REV 1

3.6.2. Saving Test Results to a Test Shot

After performing a test, the user is presented the option to save the test results to the unit’s
Flash EEPROM or to a USB Flash Drive. If the test results are not saved immediately after
performing a test, they will still remain in the working memory and can be saved later, as long
as a new test has not been performed and the unit has not been turned off. Follow the steps
below to save the test results from the working memory to a test record (the following
procedure can also be used to re-save a restored test record to a new memory location or to a
USB Flash Drive):

a. Perform a test or restore a test record to the working memory (see section 3.6.3 and

3.6.4), and then start from the “START-UP” menu:

Press the

[3]

key (SETUP).

b. The following screen will be displayed:

Press the

[2]

key (SAVE / RESTORE)

c. The following screen will be displayed:

NOTE

Option 5 (COPY TO THUMB DRIVE) will be listed only if a USB Flash drive is
connected to the CT-3500 S2.

Press the

[1]

key (SAVE SHOT).

1. SAVE SHOT
2. RESTORE SHOT
3. SHOT DIRECTORY
4. ERASE SHOT
5. COPY TO THUMB DRIVE

1. SHOT DESCRIPTION
2. SAVE / RESTORE
3. SET 50/60 HZ
4. SET DATE & TIME

1. TIME BRKR 05/16/12
2. GET RSLT 09:55:55
3. SETUP
4. DIAGNOSTICS
